Cisco X2-10GB-LR  10GBASE-LR X2 1310nm 10km DOM Transceiver Module

7,400,000

  • Mô tả

Mô tả

Module quang Cisco X2-10GB-LR là module quang cho môi trường truyền dẫn Single Mode với bước sóng là 1550nm, khoảng cách truyền dẫn tối đa là 10km,

sử dụng đầu kết nối SC/SC (2 đầu to), Module quang X2-10GB-LR hỗ thay thế nóng, điều đó có nghĩa là cho phép bạn thay thế, cắm X2-10GB-LR=​​ vào các thiết bị

chuyển mạch (Switch), thiết bị định tuyến (Router) của cisco mà không cần phải tắt thiết bị hoặc khởi động lại thiết bị, mà thiết bị tự nhận và active để hoạt động

luôn khi module X2-10GB-LR=​ được cắm vào. Vì X2-10GB-LR=​ là module quang Single Mode do vậy để đảm bảo X2 hoạt động được thì mọi thứ phải đồng bộ,

tức là cáp quang truyền dẫn, dây nhẩy, dây đuôi chuột (Pigtail) phải là Single Mode.

Cisco module quang X2-10GB-LR=​ được dùng để thiết kế mạng LAN với các khoảng cách truyền dẫn trong phạm vi 10km, ví dụ như: giữa các tầng trong một tòa nhà,

giữa các tòa nhà. Transceiver X2-10GB-LR =​ cung cấp tốc độ truyền dẫn 10G quang do vậy chúng ta có thể sử dụng module X2-10GB-LR=​ để làm uplink

truyền dẫn dữ liệu tin cậy cho một phần vùng / một nhóm user (người sử dụng) với số lượng là 20 – 1000 users (điều này còn tùy thuộc vào yêu cầu truy xuất dữ liệu của các User).

Nếu module quang X2-10GB-LR +​ được dùng làm uplink cho việc truyền dẫn các tín hiệu Video như IP Camera, Hội Nghị Truyền Hình hay IP Tivi thì: transceiver X2-10GB-LR=​ có thể truyền tải dữ liệu cho khoảng 4330 IP Camera HD (720p), hoặc là 3250 IP Camera Full HD (1080P).

Hình ảnh Module quang X2 Cisco X2-10GB-LR được CNTTShop cung cấp

X2-10GB-LR X2 modules offer the following features and benefits.

● Industry’s smallest 10G form factor for greatest density per chassis

● Hot-swappable input/output device that plugs into an Ethernet X2 port of a Cisco switch (no need to power down if installing or replacing)

● Supports “pay-as-you-populate” model for investment protection and ease of technology migration

● Digital optical monitoring capability for strong diagnostic capabilities

● Optical interoperability with 10GBASE X2, 10GBASE X2, and 10GBASE X2 interfaces on the same link

● Cisco quality identification (ID) feature enables a Cisco platform to identify whether the module is certified and tested by Cisco

Cisco X2-10GB-LR Standards:

● GR-20-CORE: Generic Requirements for Optical Fiber and Optical Fiber Cable

● GR-326-CORE: Generic Requirements for Single-Mode Optical Connectors and Jumper Assemblies

● GR-1435-CORE: Generic Requirements for Multifiber Optical Connectors

● IEEE 802.3: 10-Gigabit Ethernet

● ITU-T G.709: Interfaces for the Optical Transport Network

● ITU-T G.975: GFEC

● ITU-T G.975.1: EFEC

● X2 MSA SFF-8431 (Optical Modules, Active Optical Cables, and Passive Twinax cables)

● X2 MSA SFF-8461 (Active Twinax cables)

Mudule quang X2-10GB-LR Được sử dụng cho các thiết bị của Cisco:

Cisco 7600 Series Router

Cisco RF Gateway Series

Cisco Catalyst 3100 Blade Switches

Cisco Nexus 7000 Series

Catalyst 3560-E Series

Catalyst 3750-E Series

Catalyst 4500 Series

Catalyst 4900 Series

Cisco ME 4900 Series

Catalyst 6500Series
